Quick 201B ESD – Desoldering Station (90W)
€333.10 (€409.71 Tax Included)
QUICK 201B ESD Vacuum desoldering station with 90 W heating power. Temperature range: 200°C – 450°C.
- Description
- Additional information
- Data
- Specification
Description
Description
Vacuum desoldering station with 90 W heating power.
features:
- ESD safe.
- Efficient pressure pump.
- Microprocessor temperature calibration system, easy temperature set.
- Heating element that operates at a low voltage of 36 Volt, safe and with a long service life.
- High quality LCD display, digital temperature calibration.
- Compact design, easy to use.
- High temperature resistant air tubes.
- Long lifetime heater.
Additional information
Additional information
| Catalog Number | 212526 |
|---|
Data
TECHNICAL DATA
Producer
- Quick
Made in
- China
Distributor
- http://www.biall.com.pl
Certificates
- Compliance with WEEE 2002/96 / EC directive (disposal)
- CE Certificate
Specification
| Heating power | 90 W |
| Pump voltage | 12 V / 2 A |
| Desoldering gun voltage | 36 V |
| Temperature range | 200°C – 450°C |
| Pump | Diaphragm |
| Vacuum pressure | 600 mm Hg |
| Tip-to-ground potential | < 2 mV |
| Tip-to-ground resistance | < 2 Ω |
| Dimensions, w×l×h | 105 × 250 × 165 mm |
| Weight | 4.0 kg |
